SUS316 Chequered Sheet/SS 304 embossed Plate

Short Description:

Stainless Steel Chequered Plate is one type of finishes available in stainless steel plates. Stainless steel is one of the most used materials for pipes, plates, sheets and coils in the world. There are different grades, specifications and dimensions. JINBAICHENG METAL is a leading manufacturer and supplier of the Stainless Steel Chequered Plate in all different grades and dimensions. There are ASTM, JIS and AISI standard plates. The material grades range as 304, 304L, 301, 201, 310S, 309S, 316L, 321, 410, 420, 430 and so on.

Send email to us Whatsapp

Product Detail

Product Tags

Stainless 316 Chequered Sheet Specification Chart

Specifications	ASTM A240 / ASME SA240
Item	Stainless Steel Plates (Hot rolled, cold rolled)
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hair line, sand blast, Brush, etching, etc
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness	0.3~10.0mm
Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
End	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Grade	ASTM /ASME SA 240 304 , 304l, 304h, 309s, 309h, 310s, 310h, 316, 316l, 316h, 316, 317l ,321, 321h, 347, 347 h, 409, 410s, 420, 430, 904l chequered Plate

SS 304 Chequered Plate Physical Composition

Grade	Density(kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (μm/m/°C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
Grade	Density(kg/m3)	Elastic Modulus (GPa)	0-100°C	0-315°C	0-538°C	at 100°C	at 500°C	Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
SS chequered 304/L/H Sheet	8000	193	17.2	17.8	18.4	16.2	21.5	500	720
Stainless Steel Chequered 316/L/H Plates	8000	193	15.9	16.2	17.5	16.3	21.5	500	740

ASME SA240 316 Chequered Plate Chemical Standard

Grade	C	Mn	Si	P	S	Cr	Ni	N	Fe
Stainless Steel Chequered 304 Plates	0.07max	2.0max	0.75max	0.045max	0.03max	min: 18.0 max: 20.0	min: 8.0 max: 10.5	—	—
Stainless Steel Chequered 304L Sheets	0.03max	2.0max	0.75max	0.045max	0.03max	min: 18.0 max: 20.0	min: 8.0 max: 12.0	0.10 max	—
Stainless Steel Chequered 304H Coil	min: 18.0 max:20.0	min: 8.0 max: 10.5	min: 0.04 max:0.10	0.75 max	2.0 max	0.045 max	0.03 max	0.10 max	—
Stainless Steel Chequered 316 Foil	Min	-	-	-	0	-	16.0	10.0	-
Stainless Steel Chequered 316 Foil	Max	0.08	2.0	0.75	0.045	0.03	18.0	14.0	0.10
Stainless Steel Chequered 316L Plates	Min	-	-	-	-	-	16.0	10.0	-
Stainless Steel Chequered 316L Plates	Max	0.03	2.0	0.75	0.045	0.03	18.0	14.0	0.10
Stainless Steel Chequered 316H Sheet	Min	0.04	0.04	0	-	-	16.0	10.0	-
Stainless Steel Chequered 316H Sheet	max	0.10	0.10	0.75	0.045	0.03	18.0	14.0	-

Stainless Steel Chequered Plate Mechanical Strength

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
304	515	205	40	92	201
304L	485	170	40	92	201
304H	515	205	40	92	201
